Description

Voltage covers: 12V
Capacity: From 55Ah to 200Ah
Designed floating service life: @ 20°C/68°F 12 years.
FA (Front Access)Series batteries are designed to be used in the area of communication, whish features on new technology in design, reasonable in structure and occupying the leading position in the same industry of the world. The estimated life of FA Series batteries under float service is up to 15 years. It can be employed in numerous application in the fields of telecommunications.

Code Nominal
Voltage
(V)
Capacity
(AH)
Dimension Weight Terminal PDF
Length Width Height Total Height Kg Lb Type Posi-
tion
mm in mm in mm in mm in
FA12-55 12 55 277 10.9 105 4.13 222 8.74 222 8.74 16.5 36.38 T17 E PDF
FA12-75 12 75 562 22.13 114 4.49 188 7.4 188 7.4 24 52.92 T19 E PDF
FA12-85 12 85 507 19.96 109 4.29 223 8.78 238 9.37 29 63.95 T17 E PDF
FA12-90 12 90 507 19.96 109 4.29 223 8.78 238 9.37 31 68.36 T17 E PDF
FA12-100 12 100 395 15.55 110 4.33 285 11.22 285 11.22 33 72.77 T17 E PDF
FA12-105 12 105 395 15.55 110 4.33 285 11.22 285 11.22 34.5 76.07 T17 E PDF
FA12-120 12 120 550 21.65 110 4.33 235 9.25 235 9.25 39.5 87.1 T17 E PDF
FA12-125 12 125 420 16.54 175 6.89 237 9.33 237 9.33 44.5 98.12 T18 E PDF
FA12-150 12 150 550 21.65 110 4.33 285 11.22 285 11.22 47 103.6 T19 E PDF
FA12-155 12 155 558 21.96 124 4.88 283 11.14 283 11.14 54 119.1 T19 E PDF
FA12-170 12 170 560 22.05 125 4.92 316 12.44 316 12.44 56 123.5 T19 E PDF
FA12-180 12 180 560 22.05 125 4.92 316 12.44 316 12.44 60 132.3 T19 E PDF
FA12-200 12 200 498 19.6 259 10.2 238 9.37 238 9.37 74 163.2 T19 E PDF
Features
- Easy maintenance and installation
- No need for extra (wrench space) above battery
- Sealed and maintenance free operation
- Non-Spillable construction design
- ABS containers and covers(UL94HB, UL94V-0) optional
- Safety valve installation for explosion proof
- Maximized energy density for installation in relay rack trays
- High quality and high reliability
- Exceptional deep discharge recovery performance
- Flexibility design for multiple install positions

Application
- Telecom
- Control Equipment
- UPS
- Communication Equipment
- Medical Equipment
- Emergency Power System
