2V Series

Voltage covers: 2V.
Capacity: 250-3000AH.
Designed floating service life: @ 20°C/68°F 20 years.
The LSE range of VRLA batteries offers outstanding erformance including a 15+ year design life and a cycle life in excess of 1200 cycles to 80% DOD. Built to the highest standards and compliant with the latest IEC 60896-21/22 standard this range also offers 100% capacity out-of-the-box and is capable of handling deep discharges for complete peace of mind. The use of flexible connectors and the ability to be installed both horizontally and vertically allows for multiple installation possibilities. This robust design uses the latest AGM technology to create a range that is suitable for many applications including both fixed and mobile telecoms, UPS, utilities and solar.

Code	Nominal Voltage (V)	Capacity (AH)	Dimension								Weight		Terminal		PDF
			Length		Width		Height		Total Height		Kg	Lb	Type	Posi- tion
			mm	in	mm	in	mm	in	mm	in
LSE2-200	2	200	172	6.77	111	4.37	330	13.00	365	14.37	14.3	31.5	T19	G
LSE2-260	2	260	184.5	7.26	109	4.29	360.5	14.19	372	14.65	17	37.5	T19	G
LSE2-300	2	300	184.5	7.26	123	4.84	360.5	14.19	372	14.65	19	41.85	T19	G
LSE2-400	2	400	184.5	7.26	166	6.54	360.5	14.19	372	14.65	26	57.27	T19	G
LSE2-500	2	500	194.5	7.66	184.5	7.26	360.5	14.19	372	14.65	31	68.28	T19	G
LSE2-600	2	600	223	8.78	184.5	7.26	360.5	14.19	372	14.65	37	81.5	T19	H
LSE2-800	2	800	154	6.06	229	9.02	555	21.85	566	22.28	52	114.54	T19	H
LSE2-1000	2	1000	229	9.02	186	7.32	555	21.85	566	22.28	62	136.57	T19	H
LSE2-1500	2	1500	229	9.02	265.5	10.45	555	21.85	566	22.28	92	202.65	T19	I
LSE2-2000	2	2000	233	9.17	349	13.74	555	21.85	566	22.28	121	266.53	T19	I
